Frame
M5 alloy chassis and rear-end, trail geometry, Horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x5.8 inches dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 6.7 inches of travel
Seat Binder
Alloy, 38.6mm
Rear Shock
Fox DHX Performance, Ride Dynamics Trail Tune, S1:230x2.4 inches, S2-S5:230x62.5mm
Fork
Fox Float 38 Rhythm, GRIP damper, two position Sweep adjustment, 15x4.3 inches QR axle, 1.7 inches offset, 6.7 inches of travel
Saddle
Bridge Comp, Hollow Cr-mo rails, 143mm
Seatpost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 4.9 inches, S2: 5.9 inches, S3-S4: 6.7 inches, S5: 190mm
Stem
Alloy Trail Stem, 1.4 inches bar bore
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 1.2 inches rise, S1: 30.7 inches width, S2-S5: 31.5 inches width
Grips
Deity Knuckleduster
Front Brake
TRP Trail EVO, 4-piston caliper, hydraulic disk, 203mm
Rear Brake
TRP Trail EVO, 4-piston caliper, hydraulic disk, 203mm
Rear Derailleur
Shimano Deore, M6100, 12pd, Shadow Plus
Shift Levers
Shimano Deore, M6100, I-Spec EV, 12 speed
Cassette
Shimano Deore M6100, 12spd w/Hyperglide+, 10-51t
Chain
Shimano Deore M6100, 12spd
Crankset
Shimano Deore, M6120, 32T ring, 2.2 inches chainline, S1-4:6.5 inches, S5: 170mm
Rims
Specialized, hookless alloy, 1.2 inches inner width, tubeless ready
Front Hub
Alloy, sealed cartridge bearings, 15x4.3 inches thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x5.8 inches thru-axle, 32h
Spokes
DT Swiss Industry
Rear Tire
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Inner Tubes
Standard, Presta valve
Product ID
221254
Weight
34.3 lbs (34 lb, 4.9 oz)
Weight Size
S3
