Frame
M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x5.8 inches dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 5.5 inches of travel
Seat Binder
Alloy, 38.6mm
Rear Shock
Marzocchi Bomber Air, Ride Dynamics Trail Tune, 2-position non-indexed compression sweep, w/ LSR adjustment, S1:210x2.0 inches, S2-S5:210x52.5mm
Fork
Marzocchi Z1, GRIP damper, two position Sweep adjustment, 15x4.3 inches Kabolt axle, 1.7 inches offset, 5.5 inches of travel
Front Brake
TRP Trail EVO, 4-piston caliper, hydraulic disk, 203mm
Rear Brake
TRP Trail EVO, 4-piston caliper, hydraulic disk, 203mm
Shift Levers
Shimano Deore, M6100, I-Spec EV, 12 speed
Rear Derailleur
Shimano Deore, M6100, 12pd, Shadow Plus
Cassette
Shimano Deore M6100, 12spd w/Hyperglide+, 10-51t
Chain
Shimano Deore M6100, 12spd
Crankset
Shimano Deore, M6120, 32T ring, 2.2 inches chainline, S1:6.5 inches, S2-S5: 170mm
Rims
Specialized, hookless alloy, 1.2 inches inner width, tubeless ready
Front Hub
Alloy, sealed cartridge bearings, 15x4.3 inches thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x5.8 inches thru-axle, 32h
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Butcher, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.3"
Inner Tubes
Standard, Presta valve
Saddle
Bridge Comp, Hollow Cr-mo rails, 143mm
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 1.2 inches rise, S1: 30.7 inches width, S2-S5: 31.5 inches width
Stem
Alloy Trail Stem, 1.4 inches bar bore
Grips
Deity Knuckleduster
SeatPost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 4.9 inches, S2: 12.0 inches, S3-S4: 6.7 inches, S5: 190mm
Product ID
221251
Weight
33.7 lbs (33 lb, 11.3 oz)
Weight Size
S3
