E-Bike
Motor
Motor
Specialized SL 1.1, custom lightweight motor
UI/Remote
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Battery
Specialized SL1-320, fully integrated, 320Wh
Charger
Custom charger, 48V System w/ SL system charger plug
Wiring Harness
Custom Specialized wiring harness w/ chargeport
Frameset
Frame
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated downtube battery, internal cable routing, fender and front rack mounts, Smooth Welds
Seat Binder
Integrated w/ frame
Cockpit
Tape
Tape
Specialized Body Geometry Contour, lock-on
Stem
Specialized Stealth Stem, alloy, 14 deg, 1.3 inches, integrated TCD mount
Handlebars
Specialized, alloy, 9-degree backsweep, 0.6 inch rise, 31.8mm
Saddle
Bridge Sport, Steel rails, 155mm
SeatPost
Specialized, alloy, dual-bolt, 1.0 inch offset, 27.2mm
Suspension
Fork
Fork
Rigid full aluminum disk, Boost™ 12x4.3 inches, front- rack-compatible
Brakes
Front Brake
Front Brake
Tektro HD-R290, hydraulic disk, 160mm
Rear Brake
Tektro HD-R290, hydraulic disk, 160mm
Drivetrain
Chainrings
Chainrings
Praxis, 44T, 104BCD
Shift Levers
SRAM NX, 11-speed
Rear Derailleur
SRAM NX, 11-speed
Cassette
Sunrace, 11spd, 11-42t
Chain
KMC e11S, 11-speed w/ Missing Link™
Crankset
Praxis, Forged alloy M30, custom offset
Wheels & Tires
Rims
Rims
700C disk, 0.9 inch rim depth, 0.8 inch internal width
Front Hub
Specialized alloy front hub disk, sealed cartridge bearings, 12x4.3 inches, Center Lock™, 24h
Rear Hub
Specialized alloy rear hub disk, Center Lock™, sealed cartridge bearings, 12x5.8 inches, 28h
Spokes
DT Swiss Industry
Front Tire
Specialized Pathfinder Sport, 700x38c
Rear Tire
Specialized Pathfinder Sport, 700x38c
Inner Tubes
Standard 1.6 inches PV 700x32-50
Accessories
Pedals
Pedals
Specialized Commuter w/ grip tape & reflectors
Headlight
Lezyne Ebike Hecto STVZO E65, 210Lumens, 12V
Taillight
Specialized integrated saddle mount, LED Technology, 12V
Bell
Simple bell
